· Plug and Play, no configuration required.

· Compact structure, miniature design with 30×30mm dimensions.

· Auto MDI/MDIX, eliminating the need for crossover cables.

· Equipped with 5 auto-negotiating 10/100Mbps 4-pin connectors with GH1.25mm pitch.

· Full duplex complies with IEEE 802.3x standard; half duplex adopts Backpressure standard.

· DC 5~48V wide input voltage, reverse polarity protection & no-power protection.

· IEEE 802.3x flow control ensures reliable data transmission.

· Fanless design ensures quiet operation.

· Contact ESD: 8KV

· Reserved external indicator LED interface.

· Auto-negotiation guarantees maximum speed for each port.

· Operating temperature: -40℃ ~ 85℃
